This range of power distribution unit are designed for installation and use in networking cabinets and racks.
To meet different need, it include 19” horizontally or higher density vertically mounted options; 1U/1.5U/2U heights; Plastic or higher quality aluminum housing cases; various power types, and different choices of functions.
| Socket Type |
IEC320 C13 |
| Input Lead |
3 x 1.5mm²X 1.8M |
| Input Plug |
IEC320 C14 |
| Rated Voltage |
250V, 50/60Hz |
| Rated Current |
10A |
| Max. Power |
2500W |
| Input Cable Entry |
Rear / Left / Right Side |
| Control Functions |
LED Power Indicator |
W/O
|
| Master Switch |
YES
|
| Mini Circuit Breaker (1-Pole, 2-Pole, 3-Pole) |
W/O
|
| Overload Protector |
W/O
|
| Protection Function |
Leakage Protector |
W/O
|
| 1-LED Surge Protector (Imax: 4.5kA, 6.5kA) |
W/O
|
| 3-LED Surge Protector with Filter (Imax: 9kA) |
W/O
|
| Hot-plug 1-LED Surge protector |
W/O
|
| Hot-plug 3-LED Surge protector |
W/O
|
| Ampere Meter |
W/O
|
| Voltage & Ampere Meter |
W/O
|
| Hot-plug Ampere Meter |
W/O
|
| Hot-plug Voltage & Ampere Meter |
W/O
|
| Other Function |
Filter for RJ11/RJ45 |
W/O
|
| Dual USB Charger 5V 1A/2A |
W/O
|
| RJ45 Lan Port |
W/O
|
| RS485 Monitor |
W/O
|
| Housing Case |
Aluminum / Plastic |
| Product Width* Depth |
44.4 * 44.4 mm (1U) |
| Optional Fittings |
2pcs φ6x16mm cross bolt, 2pcs M6 float nut, User Manual |
| Package |
1PC/Polybag + Gift Box |
| Safety Authentication |
CE |
| RoHS Compliant |
YES |
|
Item No.
|
Height
|
Description |
Color
|
| AS-BL-E10CB08 |
1.0U |
8 ways IEC C13 sockets, with Circuit Breaker |
Black |
| AS-BL-E10G10S |
1.0U |
10 ways IEC C13 sockets, Switched |
Black |
| AS-SV-E10O08 |
1.0U |
8 ways IEC C13 sockets, with Overloading protector |
Silver |
| AS-SV-E10S06S |
1.0U |
6 ways IEC C13 sockets, with Surge protection, Switched |
Silver |
| AS-BL-E15G08S |
1.5U |
8 ways IEC C13 sockets, Switched |
Black |
| AS-BL-E15P08 |
1.5U |
8 ways IEC C13 sockets, with Power indicator |
Black |
| AS-SV-E15V06 |
1.5U |
6 ways IEC C13 sockets, with Voltage & Ampere Meter |
Silver |
| AS-SV-E15L06 |
1.5U |
6 ways IEC C13 sockets, with Leakage protector |
Silver |
| ……..More items according to customer’s requirement |
