Standard
Comply with IEC60529/EN60529.10.91、GB4208-93 standard

Features
●Nine fold frame,cabinet inner installation standard
●Multi-folded periphery of the enclosure to avoid water and sundries entering into the inner enclosure
●Double layer structure door,and eauipped with heat insulation coffon,effectively guarantee the opearting environment in the cabinet
●Inner cabinet adopt 19''standard installation,also can book according inner equipment
●All-round polyurethane gasket in the door with good protection
●The air conditioning and heat exchanger can be installed in the door,so that the equipment cna work safely under the bad environment
●Various optional dimension and structure according to customer requirements
●Roof rainproof ventilation structure design
●Degree of protection:Ip56

Material
SPCC cold rolled steel;Thickness:front door2.0mm,others 1.2-1.5mm

Surface finish
Degreasing, phosphoric, powder coated

Optional
Plinth,mounting panel,grid filter,fan,file pocket,head lamp

Color
B=black,RAL9032
G=grey, RAL7035
